求Smith圆图程序（用MATLAB或VB或VC）
%Victor Aprea Cornell University 6/27/02
%
%Usage: plotsmithchart(Zl,Zo)
% where Zl is the Load Impedence (possibly complex)
% and Zo is the Characteristic Line Impedence
% Plots a smith chart, along with the reflection coefficient circle
% and the line of intersection with resistive component equal to 1.
% plotsmithchart
% Without any parameters draws a blank smith chart.
% Wavelengths toward the generator are labeled around the perimeter
%
%For example: plotsmithchart(25,50)
% Draws a smithchart, calculates and plots the reflection coefficient
% for a characteristic impedence of 50 ohms and a load impedence of 25 ohms,
% and draws the line of intersection with the R=1 circle.
function answer = plotSmithChart(Zl,Zo);
constant = linspace(0,10,5);
phaseAngle = linspace(0,2*pi,50);
unitGamma = exp(j*phaseAngle);
%plot the unit circle in the complex plane
hold on;
plot(real(unitGamma),imag(unitGamma),'r');
%set(gcf,'Position',[0 0 1280 990]);
axis square
zoom on
axis([-1.1 1.1 -1.1 1.1]);
MAX=2001;
bound2=0;
bound3=0;
min_bound1=0;
min_bound2=0;
max_bound2=0;
H=0;
word=0;
Gr = linspace(-1,1,MAX);
hold on;
interval = [[.01:.01:.2],[.22:.02:.5],[.55:.05:1],[1.1:.1:2],[2.2:.2:5],[6:10],[12:2:20],[30:10:50]];
interval2= [[.01:.01:.5],[.55:.05:1],[1.1:.1:2],[2.2:.2:5],[6:10],[12:2:20],[30:10:50]];
%plot real axis
plot(Gr, zeros(1,length(Gr)),'r');
%equations were derived using the symbolic toolbox as follows
%solve('R=(1-Gr^2-Gi^2)/((1-Gr)^2+Gi^2)','Gi')
%bound was derived as follows
%solve('1/(R+1)*(-(R+1)*(R-2*R*Gr+R.*Gr^2-1+Gr^2))^(1/2)=0','Gr')
for R = interval2,
min_bound1 = (R-1)/(R+1);
if(R.2)
if(mod(R,.1)==0)
max_bound = (-1+2^2+R^2)/(2^2+R^2+2*R+1);
elseif(mod(R,.02)==0)
max_bound = (-1+.5^2+R^2)/(.5^2+R^2+2*R+1);
else
max_bound = (-1+.2^2+R^2)/(.2^2+R^2+2*R+1);
if(R==.05 | (R.151 R.149))
min_bound2 = (-1+.5^2+R^2)/(.5^2+R^2+2*R+1);
max_bound2 = (-1+1^2+R^2)/(1^2+R^2+2*R+1);
end
end
elseif(R1)
if(mod(R,.2)==0)
max_bound = (-1+5^2+R^2)/(5^2+R^2+2*R+1);
elseif(mod(R,.1)==0)
max_bound = (-1+2^2+R^2)/(2^2+R^2+2*R+1);
elseif(R==.25 | R==.35 | R==.45)
temp = (-1+.5^2+R^2)/(.5^2+R^2+2*R+1);
min_bound2 = max(min_bound1, temp);
max_bound = (-1+1^2+R^2)/(1^2+R^2+2*R+1);
elseif(R.5)
max_bound = (-1+.5^2+R^2)/(.5^2+R^2+2*R+1);
else
max_bound = (-1+1^2+R^2)/(1^2+R^2+2*R+1);
end
elseif(R5)
if(mod(R,2)==0)
max_bound = (-1+20^2+R^2)/(20^2+R^2+2*R+1);
elseif(mod(R,1)==0)
max_bound = (-1+10^2+R^2)/(10^2+R^2+2*R+1);
elseif(R2)
max_bound = (-1+5^2+R^2)/(5^2+R^2+2*R+1);
else
if(mod(R,.2)==0)
max_bound = (-1+5^2+R^2)/(5^2+R^2+2*R+1);
else
max_bound = (-1+2^2+R^2)/(2^2+R^2+2*R+1);
end
end
elseif(R10)
if(mod(R,2)==0)
max_bound = (-1+20^2+R^2)/(20^2+R^2+2*R+1);
else
max_bound = (-1+10^2+R^2)/(10^2+R^2+2*R+1);
end
else
if(R==10|R==20)
max_bound = (-1+50^2+R^2)/(50^2+R^2+2*R+1);
elseif(R==50)
max_bound = 1;
elseif(R20)
max_bound = (-1+20^2+R^2)/(20^2+R^2+2*R+1);
else
max_bound = (-1+50^2+R^2)/(50^2+R^2+2*R+1);
end
end
index = ceil((min_bound1+1)*(MAX-1)/2+1);
actual_value = Gr(index);
if(actual_valuemin_bound1)
index = index + 1;
end
MIN=index;
index = ceil((max_bound+1)*(MAX-1)/2+1);
actual_value = Gr(index);
if(actual_valuemax_bound)
index = index - 1;
end
MIN2 = ceil((min_bound2+1)*(MAX-1)/2+1);
actual_value = Gr(MIN2);
if(actual_valuemin_bound2 )
MIN2 = MIN2 + 1;
end
MAX2 = ceil((max_bound2+1)*(MAX-1)/2+1);
actual_value = Gr(MAX2);
if(actual_valuemax_bound2 )
MAX2 = MAX2 + 1;
end
r_L_a=1/(R+1)*(-(R+1)*(R-2*R.*Gr(MIN:index)+R.*Gr(MIN:index).^2-1+Gr(MIN:index).^2)).^(1/2);
r_L_b=-1/(R+1)*(-(R+1)*(R-2*R.*Gr(MIN:index)+R.*Gr(MIN:index).^2-1+Gr(MIN:index).^2)).^(1/2);
r_L_b(1)=0;
r_L_a(1)=0;
r_L_a2=1/(R+1)*(-(R+1)*(R-2*R.*Gr(MIN2:MAX2)+R.*Gr(MIN2:MAX2).^2-1+Gr(MIN2:MAX2).^2)).^(1/2);
r_L_b2=-1/(R+1)*(-(R+1)*(R-2*R.*Gr(MIN2:MAX2)+R.*Gr(MIN2:MAX2).^2-1+Gr(MIN2:MAX2).^2)).^(1/2);
r_L_a3=1/(R+1)*(-(R+1)*(R-2*R.*Gr(MIN2:index)+R.*Gr(MIN2:index).^2-1+Gr(MIN2:index).^2)).^(1/2);
r_L_b3=-1/(R+1)*(-(R+1)*(R-2*R.*Gr(MIN2:index)+R.*Gr(MIN2:index).^2-1+Gr(MIN2:index).^2)).^(1/2);
%fix resolution issues in .2-.5 range
if(~(R.2 R.5 ~(mod(R,.02)==0)))
if(R==1)
color = 'r';
else
color ='b';
end
plot(Gr(MIN:index),r_L_a(1:index-MIN+1),color,Gr(MIN:index), r_L_b(1:index-MIN+1),color);
if(R=1)
if(mod(R,1)==0)
word = [num2str(R) '.0'];
else
word = num2str(R);
end
if(mod(R,.1)==0)
set(text(Gr(MIN),0,word),'Rotation',90,'HorizontalAlignment','left','VerticalAlignment','bottom');
end
elseif(R=2)
if(mod(R,.2)==0)
if(mod(R,1)==0)
word = [num2str(R) '.0'];
else
word = num2str(R);
end
set(text(Gr(MIN),0,word),'Rotation',90,'HorizontalAlignment','left','VerticalAlignment','bottom');
end
elseif(R=5)
if(mod(R,1)==0)
set(text(Gr(MIN),0,[num2str(R) '.0']),'Rotation',90,'HorizontalAlignment','left','VerticalAlignment','bottom');
end
else
if(mod(R,10)==0)
set(text(Gr(MIN),0,num2str(R)),'Rotation',90,'HorizontalAlignment','left','VerticalAlignment','bottom');
end
end
elseif(R==.25 | R==.35 | R==.45)
plot(Gr(MIN2:index),r_L_a3,'b');
plot(Gr(MIN2:index),r_L_b3,'b');
end
if(R==.05 | (R.149 R.151))
plot(Gr(MIN2:MAX2),r_L_a2(length(Gr(MIN2:MAX2))-length(r_L_a2)+1:length(r_L_a2)),'b');
plot(Gr(MIN2:MAX2),r_L_b2(length(Gr(MIN2:MAX2))-length(r_L_b2)+1:length(r_L_b2)),'b');
end
end
%equations were derived using the symbolic toolbox as follows
%solve('2*Gi/((1-Gr)^2+Gi^2)=x','Gi')
%bound was derived as follows
%solve('1-X^2+2*X^2*Gr-X^2*Gr^2=0','Gr')
%solve('1/2/X*(2+2*(1-X^2+2*X^2*Gr-X^2*Gr^2)^(1/2))=(1-Gr^2)^(1/2)','Gr')
for X = interval,
inter_bound = (-1+X^2)/(X^2+1); %intersection with unit circle: all values must be less than this\
imag_bound = (-1+X)/X; %boundary of imagination: all values must be greater than this
angle_point = 0;
if(inter_bound ~= 0)
angle_point = sqrt(1-inter_bound^2)/inter_bound;
end
imag_bound_y = 1/2/X*(-2+2*(1-X^2+2*X^2.*inter_bound-X^2.*inter_bound.^2).^(1/2));
imag_rad = (imag_bound^2 + imag_bound_y^2)^(1/2);
condition = imag_rad 1;
if(inter_bound 1)
inter_bound = 1;
elseif(inter_bound -1)
imag_bound=-1;
end
if(imag_bound 1)
imag_bound = 1;
elseif(imag_bound -1)
imag_bound=-1;
end
%used solve function to find intersection of appropriate circle with corresponding hyperbolics
%solve('-1/(R+1)*(-(R+1)*(R-2*R*Gr+R*Gr^2-1+Gr^2))^(1/2)=1/2/X*(-2+2*(1-X^2+2*X^2*Gr-X^2*Gr^2)^(1/2))','Gr')
%The following conditional tree creates the internal bounding between the two types of curves for variable resolution
if(X.2)
if(mod(X,.1)==0)
max_bound = (-1+X^2+2^2)/(X^2+2^2+2*2+1);
elseif(mod(X,.02)==0)
max_bound = (-1+X^2+.5^2)/(X^2+.5^2+2*.5+1);
else
max_bound = (-1+X^2+.2^2)/(X^2+.2^2+2*.2+1);
end
elseif(X1)
if(mod(X,.2)==0)
max_bound = (-1+X^2+5^2)/(X^2+5^2+2*5+1);
elseif(mod(X,.1)==0)
max_bound = (-1+X^2+2^2)/(X^2+2^2+2*2+1);
elseif(X.5)
max_bound = (-1+X^2+.5^2)/(X^2+.5^2+2*.5+1);
else
max_bound = (-1+X^2+1^2)/(X^2+1^2+2*1+1);
end
elseif(X5)
if(mod(X,2)==0)
max_bound = (-1+X^2+20^2)/(X^2+20^2+2*20+1);
elseif(mod(X,1)==0)
max_bound = (-1+X^2+10^2)/(X^2+10^2+2*10+1);
elseif(X2)
max_bound = (-1+X^2+5^2)/(X^2+5^2+2*5+1);
else
if(mod(X,.2)==0)
max_bound = (-1+X^2+5^2)/(X^2+5^2+2*5+1);
else
max_bound = (-1+X^2+2^2)/(X^2+2^2+2*2+1);
end
end
elseif(X10)
if(mod(X,2)==0)
max_bound = (-1+X^2+20^2)/(X^2+20^2+2*20+1);
else
max_bound = (-1+X^2+10^2)/(X^2+10^2+2*10+1);
end
else
if(X==10|X==20)
max_bound = (-1+X^2+50^2)/(X^2+50^2+2*50+1);
elseif(X==50)
max_bound = 1;
elseif(X20)
max_bound = (-1+X^2+20^2)/(X^2+20^2+2*20+1);
else
max_bound = (-1+X^2+50^2)/(X^2+50^2+2*50+1);
end
end
inter_index = ceil((inter_bound+1)*(MAX-1)/2+1);
imag_index = ceil((imag_bound+1)*(MAX-1)/2+1);
index4 = ceil((max_bound+1)*(MAX-1)/2+1);
index1 = max(inter_index,imag_index); %maximum index for c,d
index2 = min(imag_index,inter_index); %minimum index for c,d
if(condition)
index3=imag_index;
else
index3=inter_index;
end
actual_value1 = Gr(index1);
actual_value2 = Gr(index2);
actual_value3 = Gr(index3);
actual_value4 = Gr(index4);
if((actual_value1 inter_bound index1 == inter_index)|(actual_value1 imag_bound index1 == imag_index))
index1 = index1 - 1;
end
if((actual_value2 inter_bound index2 == inter_index)|(actual_value2 imag_bound index2 == imag_index))
index2 = index2 + 1;
end
if((actual_value3 inter_bound index3 == inter_index)|(actual_value3 imag_bound index3 == imag_index))
index3 = index3 + 1;
end
if(actual_value4 max_bound)
index4 = index4 - 1;
end
MIN=index2;
MAX2=index1;
MAX3=index4;
MIN2 = index3;
% actual_value1 = Gr(MIN);
% actual_value2 = Gr(MAX2);
% MIN=1;
% MAX2=MAX;
% MIN2=1;
x_L_a = real(1/2/X*(-2+2*(1-X^2+2*X^2.*Gr(MIN2:MAX3)-X^2.*Gr(MIN2:MAX3).^2).^(1/2)));
x_L_b = real(1/2/X*(2-2*(1-X^2+2*X^2.*Gr(MIN2:MAX3)-X^2.*Gr(MIN2:MAX3).^2).^(1/2)));
x_L_c= real(1/2/X*(2+2*(1-X^2+2*X^2.*Gr(MIN:MAX2)-X^2.*Gr(MIN:MAX2).^2).^(1/2)));
x_L_d= real(1/2/X*(-2-2*(1-X^2+2*X^2.*Gr(MIN:MAX2)-X^2.*Gr(MIN:MAX2).^2).^(1/2)));
if(MIN2MAX3)
x_L_c(1)=x_L_b(1);
x_L_d(1)=x_L_a(1);
end
check1 = abs(round(10000*1/2/X*(-2-2*(1-X^2+2*X^2*inter_bound-X^2*inter_bound^2)^(1/2))));
check2 = abs(round(10000*(1-inter_bound^2)^(1/2)));
if(imag_bound -1 check1 == check2)
plot(Gr(MIN:MAX2),x_L_c,'g')
plot(Gr(MIN:MAX2),x_L_d,'g')
end
plot(Gr(MIN2:MAX3),x_L_a,'g')
plot(Gr(MIN2:MAX3),x_L_b,'g')
condition = Gr(MIN2)^2 + x_L_d(1)^2 .985;
if(X=1)
if(mod(X,.1)==0)
if(mod(X,1)==0)
word = [num2str(X) '.0'];
else
word = num2str(X);
end
if(X==1)
angle = 90;
else
angle = -atan(angle_point)*180/pi;
end
set(text(Gr(MIN2),x_L_d(1),word),'Rotation',angle,'VerticalAlignment','bottom','HorizontalAlignment','left');
set(text(Gr(MIN2),-x_L_d(1),word),'Rotation',-angle+180,'HorizontalAlignment','right','VerticalAlignment','bottom');
if(mod(X,.2)==0)
xval=X^2/(X^2+4);
yval = 1/2/X*(-2+2*(1-X^2+2*X^2*xval-X^2*xval^2)^(1/2));
angle = -atan(yval/(.5-xval))*180/pi;
set(text(xval,yval,word),'Rotation',angle,'HorizontalAlignment','left','VerticalAlignment','bottom');
set(text(xval,-yval,word),'Rotation',-angle+180,'HorizontalAlignment','right','VerticalAlignment','bottom')
end
end
elseif(X=2)
if(mod(X,.2)==0)
if(mod(X,1)==0)
word = [num2str(X) '.0'];
else
word = num2str(X);
end
if(condition)
angle = -atan(angle_point)*180/pi+180;
set(text(Gr(MIN2),x_L_a(1),word),'Rotation',angle,'VerticalAlignment','bottom','HorizontalAlignment','left');
set(text(Gr(MIN2),-x_L_a(1),word),'Rotation',-angle+180,'HorizontalAlignment','right','VerticalAlignment','bottom');
else
angle = -atan(angle_point)*180/pi+180;
set(text(Gr(MAX2),x_L_d(length(x_L_d)),word),'Rotation',angle,'VerticalAlignment','bottom','HorizontalAlignment','left');
set(text(Gr(MAX2),-x_L_d(length(x_L_d)),word),'Rotation',-angle+180,'HorizontalAlignment','right','VerticalAlignment','bottom');
end
end
elseif(X=5)
if(mod(X,1)==0)
if(condition)
angle = -atan(angle_point)*180/pi+180;
set(text(Gr(MIN2),x_L_a(1),[num2str(X) '.0']),'Rotation',angle,'VerticalAlignment','bottom','HorizontalAlignment','left');
set(text(Gr(MIN2),-x_L_a(1),[num2str(X) '.0']),'Rotation',-angle+180,'HorizontalAlignment','right','VerticalAlignment','bottom');
else
angle = -atan(angle_point)*180/pi+180;
set(text(Gr(MAX2),x_L_d(length(x_L_d)),[num2str(X) '.0']),'Rotation',angle,'VerticalAlignment','bottom','HorizontalAlignment','left');
set(text(Gr(MAX2),-x_L_d(length(x_L_d)),[num2str(X) '.0']),'Rotation',-angle+180,'HorizontalAlignment','right','VerticalAlignment','bottom');
end
end
else
if(mod(X,10)==0)
if(condition)
angle = -atan(angle_point)*180/pi+180;
set(text(Gr(MIN2),x_L_a(1),num2str(X)),'Rotation',angle,'VerticalAlignment','bottom','HorizontalAlignment','left');
set(text(Gr(MIN2),-x_L_a(1),num2str(X)),'Rotation',-angle+180,'HorizontalAlignment','right','VerticalAlignment','bottom');
else
angle = -atan(angle_point)*180/pi+180;
set(text(Gr(MAX2),x_L_d(length(x_L_d)),num2str(X)),'Rotation',angle,'VerticalAlignment','bottom','HorizontalAlignment','left');
set(text(Gr(MAX2),-x_L_d(length(x_L_d)),num2str(X)),'Rotation',-angle+180,'HorizontalAlignment','right','VerticalAlignment','bottom');
end
end
end
end
%plot imaginary axis
plot(zeros(1,length(Gr)),Gr,'r');
wavelengths = 0:.01:.5;
angle = linspace(pi,-pi,length(wavelengths));
wave_circle = 1.05*exp(j*phaseAngle);
plot(real(wave_circle),imag(wave_circle),'r');
for i=1:length(wavelengths)-1,
x=real(1.025*exp(j*angle(i)));
y=imag(1.025*exp(j*angle(i)));
if(x0)
rot_angle=atan(y/x)*180/pi-90;
else
rot_angle=atan(y/x)*180/pi+90;
end
if(wavelengths(i)==0)
word = '0.00';
elseif(mod(wavelengths(i),.1)==0)
word = [num2str(wavelengths(i)) '0'];
else
word = num2str(wavelengths(i));
end
set(text(x,y,word),'Rotation',rot_angle,'VerticalAlignment','middle','HorizontalAlignment','center');
end
%plot reflection coefficient and line of intersection only if arguments are present
if(nargin == 2)
radius = abs((Zl-Zo)/(Zl+Zo));
Load_circle=radius*exp(j*phaseAngle);
plot(real(Load_circle),imag(Load_circle),'r');
slope = (-(1-radius^2)^(1/2)*radius)/(radius^2);
value=1/(1+slope^2)^(1/2);
MAX2 = ceil((value+1)*(MAX-1)/2+1);
actual_value = Gr(MAX2);
if(actual_valuevalue)
MAX2 = MAX2 - 1;
end
%plot line of intersection
line = slope*Gr(fix(MAX/2):MAX2);
plot(Gr(fix(MAX/2):MAX2),line,'r');
end
求人脸几何特征提取VC++源代码
基于Gabor特征提取和人工智能的人脸检测系统源代码Face Detection System
这是一个使用了Gabor特征提取和人工智能的人脸检测系统源代码关键内容
使用步骤：
1. 拷贝所有文件到MATLAB工作目录下(确认已经安装了图像处理工具箱和人工智能工具箱)
2. 找到"main.m"文件
3. 命令行中运行它
4. 点击"Train Network"，等待程序训练好样本
5. 点击"Test on Photos"，选择一个.jpg图片，识别。
6. 等待程序检测出人脸区域
createffnn.m, drawrec.m, gabor.m, im2vec.m, imscan.m, loadimages.m, main.m, template1.png, template2.png, trainnet.m
MIN2 = ceil((min_bound2+1)*(MAX-1)/2+1); actual_value = Gr(MIN2); if(actual_valuemin_bound2 ) MIN2 = MIN2 + 1; end
t','bottom'); end else if(mod(R,10)==0) set(text(Gr(MIN),0,num2str(R)),'Rotation',90,'HorizontalA
