文章目录：
- 1、求串口调试助手VB源程序
- 2、各位英雄好汉，小弟跪求串口调试精灵 /或调试助手的VB.NET代码，谢谢，感激不尽！
- 3、vb编写的串口调试程序
- 4、谁能共享一下VB语言编写RS485串口通讯源代码？
- 5、用VB编写串口调试工具
求串口调试助手VB源程序
据我所知，串口调试助手
是
VC
编写的吧
或许
有
VB源程序
祝你顺利
各位英雄好汉，小弟跪求串口调试精灵 /或调试助手的VB.NET代码，谢谢，感激不尽！
太阳雨多年积攒极其珍贵的原创VB串口通信技术资料V4.0 (600M)
VB串口通信编程源码200个,多种行业多种应用...
VB串口通信技术文章160篇,详尽地对VB串口通信的诠释...
VB串口通信电子书籍16部,工业通信名家著作,经典细致...
VB串口通信控件16个,简化串口通信编码,提高开发效率...
VB串口视频教程44个,一套完整视频教程,讲解直观,更快掌握...
超级赠品一:OSI网络模型教程48M
超级赠品二:串口硬件层知识大全资料包24M
超级赠品三:串口调试工具80个,应用于各种串口调试与校验计算...
超级赠品四:程序员发展类文章和书籍12部,帮助您的成长,健康和发展....
超级赠品五:更送虚拟串口调试软件, 帮助你在没有串口的电脑上也能正常调试...
你在淘宝搜索“太阳雨VB串口资料”就可以找到，希望可以帮助到你。
同时,还有"太阳雨VC串口资料"和"太阳雨DELPHI"串口资料...
vb编写的串口调试程序
串口
接收
可以放在MScomm控件的
OnComm
事件里
推荐看书
Visual_Basic与_RS-232_串行通信控制
谁能共享一下VB语言编写RS485串口通讯源代码？
If MSComm1.PortOpen = True Then MSComm1.PortOpen = False
MSComm1.CommPort = i1
MSComm1.PortOpen = True
MSComm1.InputMode = comInputModeBinary
MSComm1.InBufferCount = 0
MSComm1.InputLen = 0
MSComm1.Settings = "9600,N,8,1"
MSComm1.RThreshold = 1
MSComm1.OutBufferCount = 0
用VB编写串口调试工具
是用VB调试精灵的源代码改过来的，以16进制方式显示发送：
Option Explicit
Dim intTime As Integer
Private strSendText As String '发送文本数据
Private bytSendByte() As Byte '发送二进制数据
Private blnReceiveFlag As Boolean
Private blnAutoSendFlag As Boolean
Private intPort As Integer
Private strSet As String
Private intReceiveLen As Integer
Private bytReceiveByte() As Byte
Private strAscii As String '设置初值
Private strHex As String
Private intHexWidth As Integer
Private intLine As Integer
Private m As Integer
Private strAddress As String
'字符表示的十六进制数转化为相应的整数,错误则返回 -1
Function ConvertHexChr(str As String) As Integer
Dim test As Integer
test = Asc(str)
If test = Asc("0") And test = Asc("9") Then
test = test - Asc("0")
ElseIf test = Asc("a") And test = Asc("f") Then
test = test - Asc("a") + 10
ElseIf test = Asc("A") And test = Asc("F") Then
test = test - Asc("A") + 10
Else
test = -1 '出错信息
End If
ConvertHexChr = test
End Function
'字符串表示的十六进制数据转化为相应的字节串,返回转化后的字节数
Function strHexToByteArray(strText As String, bytByte() As Byte) As Integer
Dim HexData As Integer '十六进制(二进制)数据字节对应值
Dim hstr As String * 1 '高位字符
Dim lstr As String * 1 '低位字符
Dim HighHexData As Integer '高位数值
Dim LowHexData As Integer '低位数值
Dim HexDataLen As Integer '字节数
Dim StringLen As Integer '字符串长度
Dim Account As Integer
Dim n As Integer
'计数
'txtSend = "" '设初值
HexDataLen = 0
strHexToByteArray = 0
StringLen = Len(strText)
Account = StringLen \ 2
ReDim bytByte(Account)
For n = 1 To StringLen
Do '清除空格
hstr = Mid(strText, n, 1)
n = n + 1
If (n - 1) StringLen Then
HexDataLen = HexDataLen - 1
Exit For
End If
Loop While hstr = " "
Do
lstr = Mid(strText, n, 1)
n = n + 1
If (n - 1) StringLen Then
HexDataLen = HexDataLen - 1
Exit For
End If
Loop While lstr = " "
n = n - 1
If n StringLen Then
HexDataLen = HexDataLen - 1
Exit For
End If
HighHexData = ConvertHexChr(hstr)
LowHexData = ConvertHexChr(lstr)
If HighHexData = -1 Or LowHexData = -1 Then '遇到非法字符中断转化
HexDataLen = HexDataLen - 1
Exit For
Else
HexData = HighHexData * 16 + LowHexData
bytByte(HexDataLen) = HexData
HexDataLen = HexDataLen + 1
End If
Next n
If HexDataLen 0 Then '修正最后一次循环改变的数值
HexDataLen = HexDataLen - 1
ReDim Preserve bytByte(HexDataLen)
Else
ReDim Preserve bytByte(0)
End If
If StringLen = 0 Then '如果是空串,则不会进入循环体
strHexToByteArray = 0
Else
strHexToByteArray = HexDataLen + 1
End If
End Function
Private Sub cmdManualSend_Click()
If Not Me.MSComm.PortOpen Then
Me.MSComm.CommPort = intPort
Me.MSComm.Settings = strSet
Me.MSComm.PortOpen = True
End If
Call ctrTimer_Timer
If Not blnAutoSendFlag Then
Me.MSComm.PortOpen = False
End If
End Sub
Private Sub cmdAutoSend_Click()
If blnAutoSendFlag Then
Me.ctrTimer.Enabled = False
If Not blnReceiveFlag Then
Me.MSComm.PortOpen = False
End If
Me.cmdAutoSend.Caption = "自动发送"
Else
If Not Me.MSComm.PortOpen Then
Me.MSComm.CommPort = intPort
Me.MSComm.Settings = strSet
Me.MSComm.PortOpen = True
End If
Me.ctrTimer.Interval = intTime
Me.ctrTimer.Enabled = True
Me.cmdAutoSend.Caption = "停止发送"
End If
blnAutoSendFlag = Not blnAutoSendFlag
End Sub
Private Sub ctrTimer_Timer()
Dim longth As Integer
strSendText = Me.txtSend.Text
longth = strHexToByteArray(strSendText, bytSendByte())
If longth 0 Then
Me.MSComm.Output = bytSendByte
End If
End Sub
'输入处理,处理接收到的字节流,并保存在全局变量
Private Sub InputManage(bytInput() As Byte, intInputLenth As Integer)
Dim n As Integer '定义变量及初始化
ReDim Preserve bytReceiveByte(intReceiveLen + intInputLenth)
For n = 1 To intInputLenth Step 1
bytReceiveByte(intReceiveLen + n - 1) = bytInput(n - 1)
Next n
intReceiveLen = intReceiveLen + intInputLenth
End Sub
'为输出准备文本,保存在全局变量
'总行数保存在intLine
Public Sub GetDisplayText()
Dim n As Integer
Dim intValue As Integer
Dim intHighHex As Integer
Dim intLowHex As Integer
Dim strSingleChr As String * 1
Dim intAddress As Integer
Dim intAddressArray(8) As Integer
Dim intHighAddress As Integer
strAscii = "" '设置初值
strHex = ""
strAddress = ""
'获得16进制码和ASCII码的字符串
For n = 1 To intReceiveLen
intValue = bytReceiveByte(n - 1)
If intValue 32 Or intValue 128 Then '处理非法字符
strSingleChr = Chr(46) '对于不能显示的ASCII码,
Else '用"."表示
strSingleChr = Chr(intValue)
End If
strAscii = strAscii + strSingleChr
intHighHex = intValue \ 16
intLowHex = intValue - intHighHex * 16
If intHighHex 10 Then
intHighHex = intHighHex + 48
Else
intHighHex = intHighHex + 55
End If
If intLowHex 10 Then
intLowHex = intLowHex + 48
Else
intLowHex = intLowHex + 55
End If
strHex = strHex + Chr$(intHighHex) + Chr$(intLowHex) + " "
If (n Mod intHexWidth) = 0 Then
strAscii = strAscii + Chr$(13) + Chr$(10)
strHex = strHex + Chr$(13) + Chr$(10)
Else
End If
Next n
txtAsc = strAscii 'Ascii
txtHex = strHex '16进制
'获得地址字符串
intLine = intReceiveLen \ intHexWidth
If (intReceiveLen - intHexWidth * intLine) 0 Then
intLine = intLine + 1
End If
'设置换行
For n = 1 To intLine
intAddress = (n - 1) * intHexWidth
intHighAddress = 8
intAddressArray(0) = intAddress
For m = 1 To intHighAddress
intAddressArray(m) = intAddressArray(m - 1) \ 16
Next m
For m = 1 To intHighAddress
intAddressArray(m - 1) = intAddressArray(m - 1) - intAddressArray(m) * 16
Next m
For m = 1 To intHighAddress
If intAddressArray(intHighAddress - m) 10 Then
intAddressArray(intHighAddress - m) = intAddressArray(intHighAddress - m) + Asc("0")
Else
intAddressArray(intHighAddress - m) = intAddressArray(intHighAddress - m) + Asc("A") - 10
End If
strAddress = strAddress + Chr$(intAddressArray(intHighAddress - m))
Next m
strAddress = strAddress + Chr$(13) + Chr$(10)
Next n
txtAdd = strAddress '地址
End Sub
Private Sub cmdReceive_Click()
If blnReceiveFlag Then
If Not blnReceiveFlag Then
Me.MSComm.PortOpen = False
End If
Me.cmdReceive.Caption = "开始接收"
Else
If Not Me.MSComm.PortOpen Then
Me.MSComm.CommPort = intPort
Me.MSComm.Settings = strSet
Me.MSComm.PortOpen = True
End If
Me.MSComm.InputLen = 0
Me.MSComm.InputMode = 0
Me.MSComm.InBufferCount = 0
Me.MSComm.RThreshold = 1
Me.cmdReceive.Caption = "停止接收"
End If
blnReceiveFlag = Not blnReceiveFlag
End Sub
Private Sub Form_Load()
intHexWidth = 8
txtAdd = ""
txtHex = ""
txtAsc = ""
txtSend = "11"
txtAdd.Width = 1335
txtHex.Width = 2535
txtAsc.Width = 1215
'设置默认发送接收关闭状态
blnAutoSendFlag = False
blnReceiveFlag = False
'接收初始化
intReceiveLen = 0
'默认发送方式为16进制
'intOutMode = 1
'初始化串行口
intPort = 1
intTime = 1000
strSet = "9600,n,8,1"
Me.MSComm.InBufferSize = 1024
Me.MSComm.OutBufferSize = 512
If Not Me.MSComm.PortOpen Then
Me.MSComm.CommPort = intPort
Me.MSComm.Settings = strSet
Me.MSComm.PortOpen = True
End If
Me.MSComm.PortOpen = False
End Sub
Private Sub cmdClear_Click()
Dim bytTemp(0) As Byte
ReDim bytReceiveByte(0)
intReceiveLen = 0
Call InputManage(bytTemp, 0)
Call GetDisplayText
Call disPlay
End Sub
Private Sub MsComm_OnComm()
Dim bytInput() As Byte
Dim intInputLen As Integer
Select Case Me.MSComm.CommEvent
Case comEvReceive
If blnReceiveFlag Then
If Not Me.MSComm.PortOpen Then
Me.MSComm.CommPort = intPort
Me.MSComm.Settings = strSet
Me.MSComm.PortOpen = True
End If
'此处添加处理接收的代码
Me.MSComm.InputMode = comInputModeBinary '二进制接收
intInputLen = Me.MSComm.InBufferCount
ReDim bytInput(intInputLen)
bytInput = Me.MSComm.Input
Call InputManage(bytInput, intInputLen)
Call GetDisplayText
'Call disPlay
If Not blnReceiveFlag Then
Me.MSComm.PortOpen = False
End If
End If
End Select
End Sub
Private Sub disPlay()
txtHex = ""
txtAsc = ""
txtAdd = ""
End Sub
